标称电压(V)
Nominal
voltage(V) |
3.2 |
3.2 |
3.2 |
标称容量(Ah)
Nominal
capacity(Ah) |
100 |
100 |
100 |
交流内阻(mΩ)
Ac internal
resistance (mΩ) |
≤0.8 |
≤0.8 |
≤0.6 |
比能量(Wh/kg)
Specific energy
(Wh/kg) |
≥155 |
≥150 |
≥155 |
最大持续/脉冲
充电倍率(C)
Maximum continuous/pulse charging rate(C) |
1C/2C |
1C/2C |
0.5C/1C |
最大持续/脉冲
放电倍率(C)
Maximum continuous/pulse discharge rate(C) |
1C/2C |
1C/2C |
0.5C/1C |
电芯尺寸(mm)
高x宽x厚
Cell Dimension (mm) HxWxD |
215.8x130x36
203.8x130x36 |
215.8x130x36
203.8x130x36 |
215.8x130x36
203.8x130x36
118.5x160x50 |
循环寿命 周
(充/放)
Cycle life (charge / discharge) |
≥4000 (0.5C/0.5C) |
≥3000 (0.5C/0.5C) |
≥1000 (0.3C/0.5C) |
重量(kg)
Weight(kg) |
2.00±0.05kg |
1.95±0.05kg |
1.95±0.05kg |
认证
Cetification |
RoHS法规 / REACH法规 / MSDS / UN38.3 / 空运 / 海运 / UL9540A / UL1642 / UL1973 / IEC 62619
RoHS regulations / REACH Regulations / MSDS / UN38.3 / Air / Sea / UL9540A / UL1642 / UL1973 / IEC 62619 |
RoHS法规 / REACH法规 / MSDS / UN38.3 / 空运 / 海运 / UL9540A / UL1642 / UL1973 / IEC 62619
RoHS regulations / REACH Regulations / MSDS / UN38.3 / Air / Sea / UL9540A / UL1642 / UL1973 / IEC 62619 |
泰尔认证 / RoHS法规 / REACH法规 / MSDS / UN38.3 / 空运 / 海运 / UL9540A / UL1642 / UL1973 / IEC 62619
Thiel certification / RoHS regulations / REACH Regulations / MSDS / UN38.3 / Air / Sea / UL9540A / UL1642 / UL1973 / IEC 62619 |
连接方式
Connection
method |
M10×1.25铝螺母
铝连接片激光焊接
M10 x 1.25
aluminum nuts
Laser welding of aluminum busbar |
M10×1.25铝螺母
铝连接片激光焊接
M10 x 1.25
aluminum nuts
Laser welding of aluminum busbar |
M10×1.25铝螺母
铝连接片激光焊接
M10 x 1.25
aluminum nuts
Laser welding of aluminum busbar |
